3MP Outdoor Bullet Network Camera
3MP Outdoor Bullet Network Camera3MP Outdoor Bullet Network Camera
Obrázky mají pouze informativní charakter a mohou se lišit od skutečnosti.

3MP Outdoor Bullet Network Camera

NETWORK Security: Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication Protocol: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS API: ONVIF Simultaneous Live View: 4 Main Streams & 3 Sub-Streams, or 3 Main Streams & 5 Sub-Streams GENERAL Package Contents: *VIGI Network Camera *Quick Start Guide *Waterproof Cable…
Kategorie: IP kamery
Kód: 3421833PN: VIGI C300HP-6Výrobce: TP-LINKZáruka: 2 roky
Výrobek pochází z oficiální české distribuce.
Aktuálně není v nabídce

Popis produktu

NETWORK

Security:Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication
Protocol:TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
API:ONVIF
Simultaneous Live View:4 Main Streams & 3 Sub-Streams, or 3 Main Streams & 5 Sub-Streams

GENERAL

Package Contents:
*VIGI Network Camera
*Quick Start Guide
*Waterproof Cable Attachments
*Mounting Bracket
*Mounting Accessories (Screws, Drywall Anchors, Hex Key)
Operating Temperature:-30–60 °C
Certifications:CE, FCC, RCM, BSMI, VCCI, IP67, RoHS
Dimensions( H X W X D ):164.9 × 87.4 × 83.4 mm
Material:Plastic
Weight:283.5g
General Features:Two Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening
Power Requirements:
*12V DC ± 5%, 5.5mm Coaxial Power Plug
*PoE (802.3af/at, class 0)

CAMERA

Image Sensor:1/2.8” Progressive Scan CMOS
Lens:4 mm / 6 mm
Aperture:
*4 mm: F2.4
*6 mm: F2.0
Lens Mount:M12
Viewing Angle:
*(4 mm) horizontal FOV: 82.5°, vertical FOV: 44.9°, diagonal FOV: 99.3°
*(6 mm) horizontal FOV: 51.9°, vertical FOV: 28.7°, diagonal FOV: 60°
Day/Night Mechanism:IR Cut Filter
IR Working Distance:30m
Minimum Illumination:Color: 0.1 Lux@F2.0; 0 Lux with IR
Weatherproof Rating:IP67
Digital Noise Reduction:3D DNR
WDR:DWDR

VIDEO/IMAGE

Video Compression:
*Main stream: H.265/H.264
*Sub-Stream: H.265/H.264
Frame Rate:1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:2304x1296, 2048x1280, 1920x1080, 1280x720, 704x576, 640x480, 352x288, 320x240
Video Streaming:
*Main Stream
*Sub-Stream
Image Settings:Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance Adjustable by Client Software
Image Enhancement:BLC/3D DNR/Prevent Overexposure to Infrared Light
Video Bit Rate:64 Kbps to 6 Mbps

SMART FEATURE-SET

Smart Event:Area Intrusion Detection, Line-Crossing Detection
Basic Event:Motion Detection, Camera Tampering Detection, Exception ( illegal login)
Linkage Method:Trigger Notification: ONVIF, HTTPS
Region of Interest:1 Region

INTERFACES

Network Interface:1 RJ45 10/100M Self-Adaptive Ethernet Port
Alarm:-
Button:-
Video Output:-

Parametry

Rozlišení (MPx)3
