MikroTik CRS112-8G-4S-IN ,8port L3 desktop switch
CRS112-8G-4S-IN
PŘEHLED/OVERVIEW
* Cloud Router Switch 112-8G-4S-IN is a “small size low cost” member of our CRS series. It comes with eight Gigabit Ethernet ports and four SFP cages.
* Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS.
* All the specific Switch configuration options are…
Kategorie: RouterBOARD
Kód: 3059424PN: CRS112-8G-4S-INVýrobce: MikroTikZáruka: 2 roky
Výrobek pochází z oficiální české distribuce.
Aktuálně není v nabídce
Popis produktu
CRS112-8G-4S-IN
PŘEHLED/OVERVIEW
* Cloud Router Switch 112-8G-4S-IN is a “small size low cost” member of our CRS series. It comes with eight Gigabit Ethernet ports and four SFP cages.
* Our CRS series combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS.
* All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.
SPECIFIKACE/SPECIFICATIONS
Details
Product code
* CRS112-8G-4S-IN
CPU nominal frequency
* 400 MHz
CPU core count
* 1
Size of RAM
* 128 MB
10/100 Ethernet ports
* None
10/100/1000 Ethernet ports
* 8
MiniPCI slots
* 0
MiniPCI-e slots
* 0
Number of USB ports
* 0
Power Jack
* 1
PoE in
* Yes
PoE out
* No
Supported input voltage
* 10 V - 57 V
Voltage Monitor
* Yes
PCB temperature monitor
* Yes
CPU temperature monitor
* No
Dimensions
* 200x143x44mm
Operating System
* RouterOS
Operating temperature range
* -30C to +70C
License level
* 5
Current Monitor
* Yes
CPU
* QCA8511-AL1C
Max Power consumption
* 13.5W
SFP ports
* 4
SFP+ ports
* 0
Serial port
* RJ45
