Počítače a kancelář  Komponenty  Základní desky  MSI MB Sc LGA1200 B460M PRO-VDH WIFI, Intel B460, 4xDDR4, VGA, mATX, WI-FI

MSI MB Sc LGA1200 B460M PRO-VDH WIFI, Intel B460, 4xDDR4, VGA, mATX, WI-FI

B460M PRO-VDH WIFI Features Supports 10th Gen Intel Core™ / Pentium Celeron processors for LGA 1200 socket Supports DDR4 Memory, up to 2933(Max) MHz Core Boost: With premium layout and digital power design to support more cores and provide better performance. DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability. Twin…
Kategorie: Základní desky
Kód: 2815545PN: B460M PRO-VDH WIFIVýrobce: MSIZáruka: 2 roky
Výrobek pochází z oficiální české distribuce.
3 233   včetně DPH
Cena bez DPH: 2 672 Kč
Nákup po telefonu
+420 587 407 456
Skladem
Kdy zboží dostanu?termín / cena přepravy
Na prodejně v Olomouci (po objednání)již zítra / ZDARMA!
Přepravní službou (ČR)již 13.7. / od 99 Kč
Na výdejním místě (ČR)14.7. / od 99 Kč
Uvedený termín je průměrná doba doručení uvedenou službou.

Popis produktu

B460M PRO-VDH WIFI

Features

  • Supports 10th Gen Intel Core™ / Pentium Celeron processors for LGA 1200 socket
  • Supports DDR4 Memory, up to 2933(Max) MHz
  • Core Boost: With premium layout and digital power design to support more cores and provide better performance.
  • DDR4 Boost: Advanced technology to deliver pure data signals for the best performance and stability.
  • Twin Turbo M.2: Running at PCI-E Gen3 x4 maximizes performance for NVMe based SSDs
  • Audio Boost: Reward your ears with studio grade sound quality
  • Steel Armor: Protecting VGA cards against bending and EMI for better performance, stability and strength.


TECHNICAL SPECIFICATIONS

CPU Supports 10th Gen Intel Core™ and Pentium Gold / Celeron processors for LGA1200 socket
Chipset Intel B460 Chipset
Memory
  • 4x DDR4 memory slots supporting up 128GB
  • Intel Core™ i7/ i9
    - Support DDR4-2933 Memory (Max.)
  • Intel Core™ i5 (Below)
    - Supports DDR4-2666 Memory (Max.)
  • Supports Dual-Channel mode
  • Supports non-ECC, un-buffered memory
  • Supports Intel Extreme Memory Profile (XMP)
Expansion Slots
  • 1x PCIe 3.0 x16 slot (from CPU)
  • 2x PCIe x1 slots (from PCH)
Onboard Graphics
  • 1x HDMI port, supporting a maximum resolution of 4096x2160 @ 30Hz, 2560x1600 @ 60Hz
  • 1x DVI-D port, supports a maximum resolution of 1920x1200 @ 60Hz
  • 1x VGA port, supports a maximum resolution of 2048x1536 @ 50Hz, 2048x1280 @ 60Hz, 1920x1200 @ 60Hz
Storage

Intel B460 Chipset

  • 4x SATA 6Gb/s ports*
  • 2x M.2 slots (Key M)
    - M2_1 supports up to PCIe 3.0 x4 and SATA 6Gb/s, 2242/ 2260/ 2280/ 22110 storage devices*
    - M2_2 supports up to PCIe 3.0 x4, 2242/ 2260/ 2280 storage devices
    - Intel Optane™ Memory Ready**
    - Supports Intel Smart Response Technology for Intel Core™ processors


* SATA1 will be unavailable when installing M.2 SATA SSD in the M2_1 slot.
** Before using Intel Optane™ memory modules, please ensure that you have updated the drivers and BIOS to the latest version from MSI website.

RAID

Intel B460 Chipset

  • Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices
Wireless LAN and Bluetooth

Intel 3168NGW

  • The Wireless module is pre-installed in the M.2 (Key-E) slot
  • Supports 802.11 a/ b/ g/ n/ ac
  • Supports Bluetooth 4.2
USB

Intel B460 Chipset

  • 6x USB 3.2 Gen 1 5Gbps ports (4 Type-A ports on the back panel, 2 ports through the internal USB connector)
  • 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors)
Audio

Realtek ALC892 Codec

  • 7.1-Channel High Definition Audio
LAN
  • 1x Realtek RTL8111H Gigabit LAN Controller
Internal Connectors
  • 1x 24-pin ATX main power connector
  • 1x 8-pin ATX 12V power connector
  • 4x SATA 6Gb/s connectors
  • 1x USB 3.2 Gen 1 5Gbps connector (support additional 2 USB 3.2 Gen 1 5Gbps ports)
  • 2x USB 2.0 connectors (support additional 4 USB 2.0 ports)
  • 1x 4-pin CPU fan connector
  • 1x 4-pin water pump connector
  • 2x 4-pin system fan connectors
  • 1x front panel audio connector
  • 2x system panel connectors
  • 1x parallel port connector
  • 1x serial port connector
  • 1x Chassis Intrusion connector
  • 1x Clear CMOS jumper
  • 1x 4-pin RGB LED connector
  • 1x 3-pin RAINBOW LED connector
  • 1x TPM module connector
Back Panel Ports
  • Keyboard / Mouse
  • VGA
  • LAN
  • USB 2.0
  • DVI-D
  • HDMI
  • USB 3.2 Gen 1 5Gbps Type-A
  • USB 3.2 Gen 1 5Gbps Type-A
  • Wireless / Bluetooth
  • Audio Connectors
Form Factor
  • mATX Form Factor
  • 9.6 in. x 9.6 in. (24.4 cm x 24.4 cm)

Parametry

Formátmicro ATX
ChipsetIntel
Integrovaná grafická kartaAno (CPU)
Integrovaná LAN karta1
PCI express 16x1
Podpora RAID1
Podpora RAID5
Podpora RAID10
RozhraníHDMI
RozhraníVGA
RozhraníUSB 2.0
RozhraníUSB 3.2
Rozhraní3.5mm Jack
RozhraníLAN
RozhraníWi-Fi
RozhraníDVI
Socket (patice)Socket 1200
Technologie paměti RAMDDR4
